Version 6.6 281 Mediant 2000
User's Manual 22. Trunk Group
22.2 Configuring Trunk Group Settings
The Trunk Group Settings allows you to configure the following per Trunk Group:
Channel select method by which IP-to-Tel calls are assigned to the Trunk Group's
channels.
Registration method for registering Trunk Groups to selected Serving IP Group IDs.
Notes:
• For configuring Trunk Groups, see Configuring Trunk Group Table on page 279.
• The Trunk Group Settings table can also be configured using the table ini file
parameter, TrunkGroupSettings (see 'Number Manipulation Parameters' on page
669).
To configure the Trunk Group Settings table:
1. Open the Trunk Group Settings page (Configuration tab > VoIP menu > GW and IP
to IP submenu > Trunk Group > Trunk Group Settings).
2. From the 'Index' drop-down list, select the range of entries that you want to edit.
3. Configure the Trunk Group as required. For a description of the parameters, see the
table below.
4. Click Submit to apply your changes.
5. To save the changes to flash memory, see 'Saving Configuration' on page 396.
Trunk Group Settings Parameters Description
Parameter Description
Trunk Group ID
[TrunkGroupSettings_Tr
unkGroupId]
Defines the Trunk Group ID that you want to configure.
Channel Select Mode
[TrunkGroupSettings_Ch
annelSelectMode]
Defines the method by which IP-to-Tel calls are assigned to the
channels of the Trunk Group.
[0] By Dest Phone Number = The channel is selected according
to the called (destination) number. If the number is not located,
the call is released. If the channel is unavailable (e.g., busy), the
call is put on call waiting (if call waiting is enabled and no other
call is on call waiting); otherwise, the call is released.
