Version 6.6 191 Mediant 2000
User's Manual 14. Services

Rule 7: Alternative routing rule that sends the call of original dialed number to IP
destination 10.33.45.72. This rule is applied in any of the following cases
• LDAP functionality is disabled.
• LDAP query is successful but call fails (due to, for example, busy line) to all the
relevant attribute destinations (private, Lync, PBX, and mobile), and a relevant
Tel-to-IP Release Reason (see Alternative Routing for Tel-to-IP Calls on page
322) has been configured.
Once the device receives the original incoming call, the first rule that it uses is Rule 6,
which queries the AD server. When the AD replies, the device searches the table, from the
first rule down, for the matching destination phone prefix (i.e., "PRIVATE:, "PBX:", "OCS:",
"MOBILE:", and "LDAP_ERR:"), and then sends the call to the appropriate destination.
14.1.3.3 Querying the AD for Calling Name
The device can be configured to retrieve the calling name (display name) from Microsoft
Active Directory (AD) for Tel-to-IP calls that are received without a calling name. The
device queries the AD, based on the Calling Number search key and searches for the
calling name attribute configured by the parameter, MSLDAPDisplayNameAttrName (e.g.,
“displayName”). The device uses the resultant calling name as the display name in the SIP
From header of the sent INVITE message.
To configure this feature, the following keywords are used in the Calling Name
Manipulation Table for Tel -> IP Calls table for the 'Prefix/Suffix to Add' fields, which can be
combined with other characters:

"$LDAP-PBX": starts LDAP query using the MSLDAPPBXAttrName parameter as the
search key

"$LDAP-MOBILE": starts LDAP query using MSLDAPMobileAttrName parameter as
the search key
If the source (calling) number of the Tel-to-IP call matches the PBX / MOBILE (e.g.,
"telephoneNumber" and "mobile") number in the AD server, the device uses the resultant
Display Name instead of the keyword(s).
For example, assume the following configuration in the Calling Name Manipulation Table
for Tel -> IP Calls:

'Source Prefix' field is set to "4".

'Prefix to Add' field is set to "$LDAP-PBX Office".
If the calling number is 4046 and the resultant LDAP query display name is "John Doe", the
device sends the INVITE message with the following From header:
From: John Doe <sip:4064@company.com>\
Notes:
• The Calling Name Manipulation Table for Tel -> IP Calls table uses the numbers
before manipulation, as inputs.
• The LDAP query uses the calling number after source number manipulation, as
the search key value.
