User's Manual 410 Document #: LTRT-68822
Mediant 2000
0567811181,0,04343434181
; number range that changes to 04343434181.
056788118[2-4],0,04343434181
If we take the first Dial Plan rule in the example above (i.e.,
"0567811181,0,04343434181"), the received Calling Number Party of 0567811181 is
changed to 04343434181 and sent to the IP with a SIP INVITE as follows:
Via: SIP/2.0/UDP 211.192.160.214:5060;branch=z9hG4bK3157667347
From: <sip:04343434181@kt.co.kr:5060>;tag=de0004b1
To: sip:01066557573@kt.co.kr:5060
Call-ID: 585e60ec@211.192.160.214
CSeq: 1 INVITE
Contact:<sip:04343434181@211.192.160.214:5060;transport=udp>
The initial Dial Plan text file must be converted to *.dat file format using the DConvert utility.
This is done by clicking the DConvert's Process Dial Plan File button. For more
information, refer to DConvert Utility User's Guide.
You can load this *.dat file to the device using the Web interface (see 'Loading Auxiliary
Files' on page 399), AcBootP utility, or using the Auto-update mechanism from an external
HTTP server.
Notes:
• Tel-to-IP routing is performed on the original source number if the parameter 'Tel
to IP Routing Mode' is set to 'Route calls before manipulation'.
• Tel-to-IP routing is performed on the modified source number as defined in the
Dial Plan file, if the parameter 'Tel To IP Routing Mode' is set to 'Route calls after
manipulation'.
• Source number Tel-to-IP manipulation is performed on the modified source
number as defined in the Dial Plan file.
33.1.5 User Information File
This section describes the various uses of the User Info file.
You can load the User Info file using any of the following methods:
Web interface (see 'Loading Auxiliary Files' on page 399)
ini file - using the UserInfoFileName parameter, e.g., UserInfoFileName =
'UserInformationFile.txt' (see 'Auxiliary and Configuration File Name Parameters' on
page
692)
Automatic update mechanism - using the UserInfoFileURL parameter, e.g.,
UserInfoFileUrl = 'http://192.168.0.250/Audiocodes/ UserInformationFile.txt' (see
'Automatic Update Mechanism' on page
423)
33.1.5.1 User Information File for PBX Extensions and "Global" Numbers
The User Info file contains a User Info table that can be used for the following Gateway-
related:
Mapping (Manipulating) PBX Extension Numbers with Global Phone Numbers:
maps PBX extension number, connected to the device, with any "global" phone
number (alphanumerical) for the IP side. In this context, the "global" phone number
serves as a routing identifier for calls in the "IP world" and the PBX extension uses this
mapping to emulate the behavior of an IP phone. This feature is especially useful in
scenarios where unique or non-consecutive number translation per PBX is needed.
This number manipulation feature supports the following call directions:
