Version 6.6 453 Mediant 2000
User's Manual 39. VoIP Status
39.8 Viewing Call Routing Status
The Call Routing Status page provides you with information on the current routing method
used by the device. This information includes the IP address and FQDN (if used) of the
Proxy server with which the device currently operates.
To view call routing status:
Open the Call Routing Status page (Status & Diagnostics tab > VoIP Status menu >
Call Routing Status).
Figure 39-8: Call Routing Status Page
Call Routing Status Parameters
Parameter Description
Call-Routing Method
Proxy/GK = Proxy server is used to route calls.
Routing Table = The Outbound IP Routing Table is used to route
calls.
IP Address
Not Used = Proxy server isn't defined.
IP address and FQDN (if exists) of the Proxy server with which the
device currently operates.
State
N/A = Proxy server isn't defined.
OK = Communication with the Proxy server is in order.
Fail = No response from any of the defined Proxies.
