Version 6.6 467 Mediant 2000
User's Manual 40. Reporting Information to External Party
"RELEASE_BECAUSE_HELD_TIMEOUT"
40.3 Configuring RADIUS Accounting
The device can send accounting data of SIP calls as call detail records (CDR) to a RADIUS
Accounting server. The device can send the accounting messages to the RADIUS server
upon call release, call connection and release, or call setup and release. For a list of the
CDR attributes, see the table following the procedure below.
Notes:
• For RADIUS accounting settings to take effect, you must save the settings to flash
memory with a device reset.
• For a description of the RADIUS accounting parameters, see 'RADIUS
Parameters' on page 539.
To configure RADIUS accounting:
1. Open the RADIUS Parameters page (Configuration tab > VoIP menu > SIP
Definitions submenu > RADIUS Parameters Settings).
Figure 40-3: RADIUS Accounting Parameters Page
2. Configure the parameters as required.
3. Click Submit.
4. For your settings to take effect, reset the device with a flash burn.
The table below describes the RADIUS Accounting CDR attributes included in the
communication packets transmitted between the device and a RADIUS server.
Supported RADIUS Accounting CDR Attributes
Attribute
Number
Attribute
Name
Vendor
Specific
Attribute
(VSA) No.
Purpose
Value
Format
Example AAA
Request Attributes
1 user-name - Account number or
calling party number
or blank
String up
to 15
digits
long
542138574
7
Start Acc
Stop Acc
4 nas-ip-
address
- IP address of the
requesting device
Numeric 192.168.14.
43
Start Acc
Stop Acc
6 service-type - Type of service
requested
Numeric 1: login Start Acc
Stop Acc
