"Inactive" - routing rule is not applied. When the destination IP
address is not on the same segment with the next hop or the
interface does not exist, the route state changes to "Inactive".
11.4.1 Interface Column
This example describes the configuration of static IP routing rules.
1. Configure network interfaces in the Multiple Interface table, as shown below:
Configured Network Interfaces in Multiple Interface Table
Index
Applicati
on Type
IP Address
Prefix
Length
Gateway VLAN ID Interface Name
0 OAMP 192.168.0.2 16 192.168.0.1 501 Mng
1
Media &
Control
10.32.174.50 24 10.32.174.1 2012 MediaCntrl
2 Media 10.33.174.50 24 10.33.174.1 2013 Media1
3 Control 10.34.174.50 24 10.34.174.1 2014 Cntrl1
2. Configure static IP Routing rules in the IP Routing table, as shown below:
Configured Static IP Routing Rules in IP Routing Table
Destination IP
Address
Prefix Length
Gateway IP
Address
Metric Interface Name
10.31.174.0 24 192.168.11.1 1 Mng
174.96.151.15 24 10.32.174.12 1 MediaCntrl
10.35.174.0 24 10.34.174.240 1 Cntrl1
Note that the IP address configured in the 'Gateway IP Address' field (i.e., next hop)
must reside on the same subnet as the IP address of the associated network interface
that is specified in the 'Interface Name' field.
11.4.2 Routing Table Configuration Summary and Guidelines
The Routing table configurations must adhere to the following rules:
Up to 30 different static routing rules can be configured.
The 'Prefix Length' replaces the dotted-decimal subnet mask presentation. This
column must have a value of 0-31 for IPv4 interfaces.
The 'Gateway IP Address' field must be on the same subnet as the IP address of the
associated interface specified in the 'Interface Name' field.
The 'Metric; field must be set to 1.
For the configuration settings to take effect, you must reset the device with a "burn" to
flash memory.
