Version 6.6 59 Mediant 2000
User's Manual 4. Web-Based Management
4.2.1 Assigning a Port Name
The Home page allows you to assign an arbitrary name or a brief description to each port.
This description appears as a tooltip when you move your mouse over the port.
Note: Only alphanumerical characters can be used in the port description.
To add a port description:
1. Click the required port icon; a shortcut menu appears, as shown below:
2. From the shortcut menu, choose Update Port Info; a text box appears.
3. Type a brief description for the port, and then click Apply Port Info.
4.2.2 Switching Between Modules
The device can house up to two modules. Since each module is a standalone gateway, the
Home page displays only one of the modules to which you are connected. However, you
can easily switch to the second module, by having the Web browser connect to the IP
address of the second module.
To switch modules:
1. In the Home page, click anywhere on the module to which you want to switch, as
shown below:
Figure 4-25: Click Module to which you want to Switch
