Item # Description
(see Viewing Active Alarms on page 439).
2 Blade Activity icon:
 (green): Initialization sequence terminated successfully
3 Blade Fail icon:
 (gray): Normal functioning
 (red): Blade failure
4 T1/E1 Trunk Status icons for trunks 1 through 8.
 (gray): Disable - Trunk not configured (not in use)
 (green): Active OK - Trunk synchronized
 (yellow): RAI Alarm - Remote Alarm Indication (RAI), also known as the
'Yellow' Alarm
 (red): LOS / LOF Alarm - Loss due to LOS (Loss of Signal) or LOF (Loss of
Frame)
 (blue): AIS Alarm - Alarm Indication Signal (AIS), also known as the 'Blue'
Alarm
 (orange): D-Channel Alarm - D-channel alarm
 (dark orange): NFAS Alarm
If you click a trunk icon, a shortcut menu appears with commands allowing you to do
the following:
 Port Settings: Displays the trunk's settings and allows you to modify them (see
Configuring Trunk Settings on page 261).
 Update Port Info: Assigns a name to the port (see 'Assigning a Port Name' on
page 59)
Note: To log in to the second module, see Logging in between Modules on page 59
.
5 Dual Ethernet Link icons:
 (gray): No link
 (green): Active link
To view detailed Ethernet port information, click this icon to open the Ethernet Port
Information page (see Viewing the Active Alarms on page 439).
6 Dual Ethernet activity icons:
 (gray): No Ethernet activity
 ( orange): Transmit / receive activity
7 T1/E1 Trunk Status icons for trunks 9 through 16. See Item #4 for a description.
8 Power status icon:
 (green): Power received by blade
 (red): No power received by blade
9 Slot status of installed blade in the chassis (SWAP Ready icon).
