User's Manual 50 Document #: LTRT-68822
Mediant 2000
Notes:
• You can add up to 20 Steps per Scenario, where each Step can contain up to 25
parameters.
• When in Scenario mode, the Navigation tree is in 'Full' display (i.e., all menus are
displayed in the Navigation tree) and the configuration pages are in 'Advanced
Parameter List' display (i.e., all parameters are shown in the pages). This ensures
accessibility to all parameters when creating a Scenario. For a description on the
Navigation tree views, see 'Navigation Tree' on page 39.
• If you previously created a Scenario and you click the Create Scenario button,
the previously created Scenario is deleted and replaced with the one you are
creating.
• Only Security Administrator Web users can create Scenarios.
4.1.8.2 Accessing a Scenario
Once you have created the Scenario, you can access it by following the procedure below:
 To access the Scenario:
1. On the Navigation bar, select the Scenario tab; a message box appears, requesting
you to confirm the loading of the Scenario.
2. Click OK; the Scenario and its Steps appear in the Navigation tree, as shown in the
example below:
Figure 4-18: Scenario Example
Loaded Scenario Description
Item # Description
1
Scenario name.
2
Scenario Steps.
3
Scenario configuration command buttons.
4
Parameters available on a page for the selected Scenario Step. These are displayed in
a blue background; unavailable parameters are displayed in a gray or light-blue
