AudioCodes Mediant 2000 User Manual

Version 6.6 493 Mediant 2000
User's Manual 43. Testing SIP Signaling Calls
The status of the test call is displayed in the 'Test Status' field of the Test Call table:

"Idle": test call is not active.

"Scheduled": test call is planned to run (according to 'Schedule Interval' parameter
settings)

"Running": test call has been started (i.e., the Dial command was clicked)

"Receiving": test call has been automatically activated by calls received for the test
call endpoint from the remote endpoint (when all these calls end, the status returns to
"Idle")

"Terminating": test call is in the process of terminating the currently established calls
(this occurs if the Drop Call command is clicked to stop the test)

"Done": test call has been successfully completed (or was prematurely stopped by
clicking the Drop Call command)
A more detailed description of this field is displayed below the table when you click the
Show/Hide button (see 'Viewing Test Call Statistics' on page 493.
43.1.2 Viewing Test Call Statistics
In addition to viewing a brief status description of the test call in the 'Test Status' field (as
described in 'Starting, Stopping and Restarting Test Calls' on page 492), you can also view
a more detailed status description which includes test call statistics.
 To view statistics of a test call:
1. Open the Test Call Table page (Configuration tab > System menu > Test Call >
Test Call Table).
2. Select the test call table entry whose call statistics you want to view.
3. Click the Show/Hide button; the call statistics are displayed in the Test Statistics
pane located below the table, as shown in the figure below:
Figure 43-2: Viewing Test Call Statistics
The 'Test Statistics' pane displays the following test session information:

Elapsed Time: Duration of the test call since it was started (or restarted).

Active Calls: The number of currently active test calls.

Call Attempts: The number of calls that were attempted.

Total Established Calls: The total number of calls that were successfully established.

Total Failed Attempts: The total number of calls that failed to be established.
