User's Manual 38 Document #: LTRT-68822
Mediant 2000
4.1.4 Toolbar Description
The toolbar provides frequently required command buttons, described in the table below:
Description of Toolbar Buttons
Icon Button
Name
Description
Submit
Applies parameter settings to the device (see 'Saving Configuration'
on page 396).
Note: This icon is grayed out when not applicable to the currently
opened page.
Burn
Saves parameter settings to flash memory (see 'Saving Configuration'
on page 396).
Device
Actions
Opens a drop-down list with frequently needed commands:
 Load Configuration File: Opens the Configuration File page for
loading an ini file to the device (see 'Backing Up and Loading
Configuration File' on page 422).
 Save Configuration File: Opens the Configuration File page for
saving the ini file to a folder on a computer (see 'Backing Up and
Loading Configuration File' on page 422).
 Reset: Opens the Maintenance Actions page for performing
various maintenance procedures such as resetting the device (see
'Resetting the Device' on page 393).
 Software Upgrade Wizard: starts the Software Upgrade wizard
for upgrading the device's software (see 'Software Upgrade
Wizard' on page 419).
Home
Opens the Home page (see 'Viewing the Home Page' on page 57).
Help
Opens the Online Help topic of the currently opened configuration
page (see 'Getting Help' on page 56).
Log off
Logs off a session with the Web interface (see 'Logging Off the Web
Interface' on page 56).
Note: If you modify a parameter that takes effect only after a device reset, after you
click the Submit button in the configuration page, the toolbar displays "Reset", as
shown in the figure below. This is a reminder that you need to later save your settings
to flash memory and reset the device.
Figure 4-3: "Reset" Displayed on Toolbar
