Version 6.6 37 Mediant 2000
User's Manual 4. Web-Based Management
Description of the Web GUI Areas
Item # Description
1
Displays AudioCodes (corporate) logo image.
2
Displays the product name.
3
Toolbar, providing frequently required command buttons. For more information, see
'Toolbar Description' on page 38.
4
Displays the username of the Web user that is currently logged in.
5
Navigation bar, providing the following tabs for accessing various functionalities in
the Navigation tree:
 Configuration, Maintenance, and Status & Diagnostics tabs: Access the
configuration menus (see 'Working with Configuration Pages' on page 41)
 Scenarios tab: Creates configuration scenarios (see Working with Scenarios on
page 48)
 Search tab: Enables a search engine for searching configuration parameters
(see 'Searching for Configuration Parameters' on page 47)
6
Navigation tree, displaying a tree-like structure of elements (configuration menus,
Scenario steps, or search engine) pertaining to the selected tab on the Navigation
bar. For more information, see 'Navigation Tree' on page 39.
7
Work pane, displaying the configuration page of the selected menu in the Navigation
tree. This is where configuration is done. For more information, see 'Working with
Configuration Pages' on page
41.
