AudioCodes Mediant 2000 User Manual

User's Manual 504 Document #: LTRT-68822
Mediant 2000
45.1.2 Multiple VoIP Network Interfaces and VLAN Parameters
The IP network interfaces and VLAN parameters are described in the table below.
IP Network Interfaces and VLAN Parameters
Parameter Description
Multiple Interface Table
Web: Multiple Interface
Table
EMS: IP Interface
Settings
[InterfaceTable]
This table parameter configures the Multiple Interface table. The format
of this parameter is as follows:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName,
InterfaceTable_PrimaryDNSServerIPAddress,
InterfaceTable_SecondaryDNSServerIPAddress,
InterfaceTable_UnderlyingInterface;
[\InterfaceTable]
For example:
InterfaceTable 0 = 0, 0, 192.168.85.14, 16, 0.0.0.0, 1, Management;
InterfaceTable 1 = 2, 0, 200.200.85.14, 24, 0.0.0.0, 200, Control;
InterfaceTable 2 = 1, 0, 211.211.85.14, 24, 211.211.85.1, 211, Media;
The above example, configures three network interfaces (OAMP,
Control, and Media).
Notes:
 For this parameter to take effect, a device reset is required.
 For a description of this parameter, see 'Configuring IP Network
Interfaces' on page 106.
Single IP Network Parameters
Web: IP Address
EMS: Local IP Address
[LocalOAMIPAddress]
Defines the device's source IP address of the operations,
administration, maintenance, and provisioning (OAMP) interface when
operating in a single interface scenario without a Multiple Interface
table.
The default is 0.0.0.0.
Note: For this parameter to take effect, a device reset is required.
Web: Subnet Mask
EMS: OAM Subnet Mask
[LocalOAMSubnetMask]
Defines the device's subnet mask of the OAMP interface when
operating in a single interface scenario without a Multiple Interface
table.
The default subnet mask is 0.0.0.0.
Note: For this parameter to take effect, a device reset is required.
Web: Default Gateway
Address
EMS: Local Def GW
[LocalOAMDefaultGW]
Defines the Default Gateway of the OAMP interface when operating in a
single interface scenario without a Multiple Interface table.
VLAN Parameters
Web/EMS: VLAN Mode
[VLANMode]
Enables VLANs tagging (IEEE 802.1Q).
 [0] Disable (default)
 [1] Enable
Notes:
