User's Manual 36 Document #: LTRT-68822
Mediant 2000
 To access the Web interface:
1. Open a standard Web browser (see 'Computer Requirements' on page 35).
2. In the Web browser, specify the IP address of the device (e.g., http://10.1.10.10); the
Web interface's Login window appears, as shown below:
Figure 4-1: Web Login Screen
3. In the 'Username' and 'Password' fields, enter the case-sensitive, user name and
password respectively.
4. Click Login; the Web interface is accessed, displaying the Home page. For a detailed
description of the Home page, see 'Viewing the Home Page' on page 57.
Notes:
• The default username and password is "Admin". To change the login user name
and password, see 'Configuring the Web User Accounts' on page 60.
• If you want the Web browser to remember your password, select the 'Remember
Me' check box and then agree to the browser's prompt (depending on your
browser) to save the password for future logins. On your next login attempt, simply
press the Tab or Enter keys to auto-fill the 'Username' and 'Password' fields, and
then click Login.
4.1.3 Areas of the GUI
The areas of the Web interface's GUI are shown in the figure below and described in the
subsequent table.
Figure 4-2: Main Areas of the Web Interface GUI
