Version 6.6 203 Mediant 2000
User's Manual 16. Control Network
3. Click Submit to apply your settings.
SIP Interface Table Parameters
Parameter Description
Network Interface
[SIPInterface_NetworkI
nterface]
Defines the Control-type IP network interface that you want to associate
with the SIP Interface. This value string must be identical (including
case-sensitive) to that configured in the 'Interface Name' field of the
Multiple Interface table (see 'Configuring IP Network Interfaces' on page
106).
The default is not configured.
Note: SIP Interfaces that are assigned to a specific SRD must be
defined with the same network interface. For example, if you define three
SIP Interfaces for SRD ID #8, all these SIP Interfaces must be defined
with the same network interface (e.g., "SIP1").
Application Type
[SIPInterface_Applicati
onType]
Defines the application type associated with the SIP Interface.
 [0] GW/IP2IP (default) = Gateway / IP-to-IP application.
 [1] SAS = Stand-Alone Survivability (SAS) application.
UDP Port
[SIPInterface_UDPPort]
Defines the listening and source UDP port.
The valid range is 1 to 65534. The default is 5060.
Notes:
 This port must be outside of the RTP port range.

Each SIP Interface must have a unique signaling port (i.e., no two SIP
Interfaces can share the same port - no port overlapping).
TCP Port
[SIPInterface_TCPPort]
Defines the listening TCP port.
The valid range is 1 to 65534. The default is 5060.
Notes:
 This port must be outside of the RTP port range.

Each SIP Interface must have a unique signaling port (i.e., no two SIP
Interfaces can share the same port - no port overlapping).
TLS Port
[SIPInterface_TLSPort]
Defines the listening TLS port.
The valid range is 1 to 65534. The default is 5061.
Notes:
