User's Manual 210 Document #: LTRT-68822
Mediant 2000
routing, at least two Proxy Sets are defined for call destination – one for each leg (IP
Group) of the call (i.e., both directions). For example, one Proxy Set for the Internet
Telephony Service provider (ITSP) interfacing with one 'leg' of the device and another
Proxy Set for the second SIP entity (e.g., ITSP) interfacing with the other 'leg' of the device.
Notes:
• Proxy Sets can be assigned only to Server-type IP Groups.
• The Proxy Set table can also be configured using two complementary tables:
- Proxy Set ID with IP addresses: Table ini file parameter, ProxyIP.
- Attributes for the Proxy Set: Table ini file parameter, ProxySet.
 To configure Proxy Sets:
1. Open the Proxy Sets Table page (Configuration tab > VoIP menu > Control
Network submenu > Proxy Sets Table).
Figure 16-1: Proxy Sets Table Page
2. From the 'Proxy Set ID' drop-down list, select an ID for the desired group.
3. Configure the Proxy parameters, as required. For a description of the parameters, see
the table below.
4. Click Submit.
5. To save the changes to flash memory, see 'Saving Configuration' on page 396.
Proxy Sets Table Parameters
Parameter Description
Web: Proxy Set ID
EMS: Index
[ProxySet_Index]
Defines the Proxy Set identification number.
The valid value is 0 to 31. Proxy Set ID 0 is used as the default Proxy Set.
Note: Although not recommended, you can use both default Proxy Set (ID
0) and IP Groups for call routing. For example, in the Trunk Group Settings
