AudioCodes Mediant 2000 User Manual

Version 6.6 217 Mediant 2000
User's Manual 17. SIP Definitions
Parameter Description
Username
[Account_Userna
me]
Defines the digest MD5 Authentication user name.
The valid value is a string of up to 50 characters.
Password
[Account_Passwo
rd]
Defines the digest MD5 Authentication password.
The valid value is a string of up to 50 characters.
Note: After you click the Apply button, this password is displayed as an
asterisk (*).
Host Name
[Account_HostNa
me]
Defines the Address of Record (AOR) host name. It appears in REGISTER
From/To headers as ContactUser@HostName. For successful registrations,
this host name is also included in the INVITE request's From header URI.
This parameter can be up to 49 characters.
Note: If this parameter is not configured or if registration fails, the 'SIP Group
Name' parameter configured in the IP Group table is used instead.
Register
[Account_Register
]
Enables registration.
 [0] No (Default)
 [1] Yes
When enabled, the device sends REGISTER requests to the Serving IP
Group. The host name (i.e., host name in SIP From/To headers) and Contact
User (user in From/To and Contact headers) are taken from this table upon
successful registration. See the example below:
REGISTER sip:xyz SIP/2.0
Via: SIP/2.0/UDP 10.33.37.78;branch=z9hG4bKac1397582418
From: <sip:ContactUser@HostName>;tag=1c1397576231
To: <sip: ContactUser@HostName >
Call-ID: 1397568957261200022256@10.33.37.78
CSeq: 1 REGISTER
Contact: <sip:ContactUser@10.33.37.78>;expires=3600
Expires: 3600
User-Agent: Sip-Gateway/v.6.00A.008.002
Content-Length: 0
Notes:
 To activate registration, you also need to set the parameter 'Registration
Mode' to 'Per Account' in the Trunk Group Settings table for the specific
Trunk Group.
 The Trunk Group account registration is not affected by the parameter
IsRegisterNeeded.
Contact User
[Account_Contact
User]
Defines the AOR user name. This appears in REGISTER From/To headers
as ContactUser@HostName, and in INVITE/200 OK Contact headers as
ContactUser@<device's IP address>.
Notes:
 If this parameter is not configured, the 'Contact User' parameter in the IP
Group table is used instead.
 If registration fails, then the user part in the INVITE Contact header
contains the source party number.
Application Type
[Account_Applicat
ionType]
Defines the application type:
 [0] GW/IP2IP = (Default) Gateway and IP-to-IP application.
