User's Manual 266 Document #: LTRT-68822
Mediant 2000
Notes:
• Don't modify the default values unless you fully understand the implications of the
changes and know the default values. Every change affects the configuration of
the state machine parameters and the call process related to the trunk you are
using with this state machine.
• You can modify CAS state machine parameters only if the following conditions are
met:
1) Trunks are inactive (stopped), i.e., the 'Related Trunks' field displays the trunk
number in green.
2) State machine is not in use or is in reset, or when it is not related to any trunk. If
it is related to a trunk, you must delete the trunk or de-activate (Stop) the trunk.
• Field values displaying '-1' indicate CAS default values. In other words, CAS state
machine values are used.
• The modification of the CAS state machine occurs at the CAS application
initialization only for non-default values (-1).
• For more information on the CAS Protocol table, refer to the CAS Protocol Table
User's Guide.
CAS State Machine Parameters Description
Parameter Description
Generate Digit On Time
[CasStateMachineGenerate
DigitOnTime]
Generates digit on-time (in msec).
The value must be a positive value. The default is -1 (use value
from CAS state machine).
Generate Inter Digit Time
[CasStateMachineGenerateI
nterDigitTime]
Generates digit off-time (in msec).
The value must be a positive value. The default is -1 (use value
from CAS state machine).
DTMF Max Detection Time
[CasStateMachineDTMFMa
xOnDetectionTime]
Detects digit maximum on time (according to DSP detection
information event) in msec units.
The value must be a positive value. The default is -1 (use value
from CAS state machine).
DTMF Min Detection Time
[CasStateMachineDTMFMin
OnDetectionTime]
Detects digit minimum on time (according to DSP detection
information event) in msec units. The digit time length must be
longer than this value to receive a detection. Any number may be
used, but the value must be less than
CasStateMachineDTMFMaxOnDetectionTime.
The value must be a positive value. The default is -1 (use value
from CAS state machine).
MAX Incoming Address Digits
[CasStateMachineMaxNum
OfIncomingAddressDigits]
Defines the limitation for the maximum address digits that need to
be collected. After reaching this number of digits, the collection of
address digits is stopped.
The value must be an integer. The default is -1 (use value from
CAS state machine).
MAX Incoming ANI Digits
[CasStateMachineMaxNum
OfIncomingANIDigits]
Defines the limitation for the maximum ANI digits that need to be
collected. After reaching this number of digits, the collection of ANI
digits is stopped.
The value must be an integer. The default is -1 (use value from
CAS state machine).
Collet ANI
In some cases, when the state machine handles the ANI collection
(not related to MFCR2), you can control the state machine to collect
To Next Page
