Version 6.6 295 Mediant 2000
User's Manual 23. Manipulation
3. Click the Rule tab, and then configure the matching characteristics. For a description
of the parameters, see the table below.
4. Click the Action tab, and then configure the manipulation operation. For a description
of the parameters, see the table below.
5. Click the Submit button to save your changes.
Calling Name Manipulation Parameters Description
Parameter Description
Matching Characteristics (Rule)
Web: Destination Prefix Defines the destination (called) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a called number. For a description of available notations,
see 'Dialing Plan Notation for Routing and Manipulation Tables' on
page 501.
Web/EMS: Source Prefix Defines the source (calling) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a calling number. For a description of available notations,
see 'Dialing Plan Notation for Routing and Manipulation Tables' on
page
501.
Web: Calling Name Prefix Defines the caller name (i.e., caller ID) prefix. You can use special
notations for denoting the prefix. For example, to denote any prefix,
use the asterisk (*) symbol or to denote calls without a calling name,
use the $ sign. For a description of available notations, see 'Dialing
Plan Notation for Routing and Manipulation Tables' on page 501.
Web: Source Trunk Group
ID
Defines the source Trunk Group ID for Tel-to-IP calls. To denote all
Trunk Groups, leave this field empty.
Notes:
 This parameter is applicable only to the Calling Name
Manipulations Tel2IP table.
 The value -1 indicates that this field is ignored in the rule.
 This parameter is applicable only to Tel-to-IP calls.
Web: Source IP Group ID Defines the IP Group from where the IP call originated.
Notes:
 This parameter is applicable only to the Calling Name
Manipulations Tel2IP table.
 The value -1 indicates that this field is ignored in the rule.
Web/EMS: Source IP
Address
Defines the source IP address of the caller, obtained from the Contact
header in the INVITE message.
Notes:
 This parameter is applicable only to the Calling Name
Manipulations IP2Tel table.
 The source IP address can include the 'x' wildcard to represent
single digits. For example: 10.8.8.xx represents all IP addresses
between 10.8.8.10 to 10.8.8.99.
 The source IP address can include the asterisk (*) wildcard to
represent any number between 0 and 255. For example, 10.8.8.*
