Version 6.6 315 Mediant 2000
User's Manual 24. Routing
Parameter Description
The number can include up to 50 digits.
Operation (IP Destination)
Web: Dest. IP
Address
EMS: Address
[PREFIX_DestAddr
ess]
Defines the IP address (in dotted-decimal notation or FQDN) to where the
call is sent. If an FQDN is used (e.g., domain.com), DNS resolution is done
according to the DNSQueryType parameter.
For ENUM-based routing, enter the string value "ENUM". The device sends
an ENUM query containing the destination phone number to an external
DNS server, configured in the Multiple Interface table. The ENUM reply
includes a SIP URI which is used as the Request-URI in the subsequent
outgoing INVITE and for routing (if a proxy is not used). To configure the
type of ENUM service (e.g., e164.arpa), use the EnumService parameter.
For LDAP-based routing, enter the string value "LDAP" for denoting the IP
address of the LDAP server. For more information, see Routing Based on
LDAP Active Directory Queries on page 183.
Notes:
 This field and any value assigned to it is ignored if you have configured a
destination IP Group for this routing rule (in the 'Dest IP Group ID' field).
 To reject calls, enter the IP address 0.0.0.0. For example, if you want to
prohibit international calls, then in the 'Dest Phone Prefix' field, enter 00
and in the 'Dest IP Address' field, enter 0.0.0.0.
 For routing calls between phones connected to the device (i.e., local
routing), enter the device's IP address.
 When the device's IP address is unknown (e.g., when DHCP is used),
enter IP address 127.0.0.1.
 When using domain names, enter the DNS server's IP address or
alternatively, configure these names in the Internal DNS table (see
'Configuring the Internal DNS Table' on page 120).
 The IP address can include the following wildcards:
"x": represents single digits. For example, 10.8.8.xx denotes all
addresses between 10.8.8.10 and 10.8.8.99.
"*": represents any number between 0 and 255. For example,
10.8.8.* denotes all addresses between 10.8.8.0 and 10.8.8.255.
Web: Port
EMS: Destination
Port
[PREFIX_DestPort]
Defines the destination port to where you want to route the call.
Web/EMS: Transport
Type
[PREFIX_Transport
Type]
Defines the transport layer type for sending the IP call:
 [-1] Not Configured
 [0] UDP
 [1] TCP
 [2] TLS
Note: When set to Not Configured (-1), the transport type defined by the
SIPTransportType parameter is used.
Web: Dest IP Group
ID
EMS: Destination IP
Group ID
[PREFIX_DestIPGro
upID]
Defines the IP Group to where you want to route the call. The SIP INVITE
message is sent to the IP address defined for the Proxy Set ID associated
with the IP Group.
Notes:
 If you select an IP Group, you do not need to configure a destination IP
address. However, if both parameters are configured in this table, the
