AudioCodes Mediant 2000 User Manual

Version 6.6 377 Mediant 2000
User's Manual 28. SAS Configuration
Note: The IP-to-IP Routing table can also be configured using the table ini file
parameter, IP2IPRouting (see 'Configuration Parameters Reference' on page 503).
 To configure the IP-to-IP Routing table for SAS:
1. In the SAS Configuration page, click the SAS Routing Table button; the IP-to-IP
Routing Table page appears.
2. Click Add; the Add Record dialog box appears:
Figure 28-9: Add Record Dialog Box of SAS IP2IP Routing Page
3. Configure the rule according to the table below.
4. Click Submit to apply your changes.
5. To save the changes to flash memory, see 'Saving Configuration' on page 396.
Note: The following parameters are not applicable to SAS and must be ignored:
• 'Source IP Group ID'
• 'Destination IP Group ID'
• 'Destination SRD ID'
• 'Alternative Route Options'
