Version 6.6 45 Mediant 2000
User's Manual 4. Web-Based Management
Item # Button / Field
Index.
5
Index radio button Selects the row for editing and deleting.
-
Compact button Organizes the index entries in ascending, consecutive
order, starting from index 0. For example, assume you have
three index entries, 0, 4 and 6. After you click Compact,
index entry 4 is re-assigned to index 1 and index entry 6 is
re-assigned to index 2.
- Apply button Saves the row configuration. Click this button after you add
or edit each index entry.
4.1.6.4.2 Enhanced Design Tables
Most of the tables in the Web interface are designed in the enhanced table format. The
figure below displays a typical table in the enhanced design format and the subsequent
table describes its command buttons and areas.
Figure 4-12: Displayed Details Pane
Enhanced Table Design Description
Item # Button
1 Add
Adds a new index entry row to the table. When you click this button, a
dialog box appears with parameters for configuring the new entry.
When you have completed configuration, click the Submit button in the
dialog box to add it to the table.
2 Edit
Edits the selected row.
3 Delete
Removes the selected row from the table. When you click this button, a
confirmation box appears requesting you to confirm deletion. Click
Delete to accept deletion.
