Version 6.6 521 Mediant 2000

User's Manual 45. Configuration Parameters Reference

Parameter Description

Note: This feature helps overcome connection problems caused by

some LAN routers or IP configuration parameters' modifications by a

DHCP server.

[EnableAutoRAITransmi

tBER]

Enable

s the device to send a remote alarm indication (RAI) when the bit

error rate (BER) is greater than 0.001.

 [0] Disable (default)

 [1] Enable

Default Chapter3
