Version 6.6 523 Mediant 2000
User's Manual 45. Configuration Parameters Reference
Parameter Description
Web/EMS: Syslog Server
IP Address
[SyslogServerIP]
Defines the IP address (in dotted-decimal notation) of the computer on
which the Syslog server is running. The Syslog server is an application
designed to collect the logs and error messages generated by the
device.
The default IP address is 0.0.0.0.
Web: Syslog Server Port
EMS: Syslog Server Port
Number
[SyslogServerPort]
Defines the UDP port of the Syslog server.
The valid range is 0 to 65,535. The default port is 514.
[MaxBundleSyslogLengt
h]
Defines the maximum size (in bytes) threshold of logged Syslog
messages bundled into a single UDP packet, after which they are sent
to a Syslog server.
The valid value range is 0 to 1220 (where 0 indicates that no bundling
occurs). The default is 1220.
Note: This parameter is applicable only if the GWDebugLevel
parameter is set to 7.
Web: CDR Server IP
Address
EMS: IP Address of CDR
Server
[CDRSyslogServerIP]
Defines the destination IP address to where CDR logs are sent.
The default is a null string, which causes CDR messages to be sent
with all Syslog messages to the Syslog server.
Notes:
 The CDR messages are sent to UDP port 514 (default Syslog port).
 This mechanism is active only when Syslog is enabled (i.e., the
parameter EnableSyslog is set to 1).
Web/EMS: CDR Report
Level
[CDRReportLevel]
Enables media- and signaling-related CDRs to be sent to a Syslog
server and determines the call stage at which they are sent.
 [0] None = (Default) CDRs are not used.
 [1] End Call = CDR is sent to the Syslog server at the end of each
call.
 [2] Start & End Call = CDR report is sent to Syslog at the start and
end of each call.
 [3] Connect & End Call = CDR report is sent to Syslog at
connection and at the end of each call.
 [4] Start & End & Connect Call = CDR report is sent to Syslog at
the start, at connection, and at the end of each call.
Notes:
 The CDR Syslog message complies with RFC 3161 and is
identified by: Facility = 17 (local1) and Severity = 6 (Informational).
 This mechanism is active only when Syslog is enabled (i.e., the
parameter EnableSyslog is set to 1).
Web/EMS: Debug Level
[GwDebugLevel]
Defines the Syslog debug logging level.
 [0] 0 = (Default) Debug is disabled.
 [1] 1 = Flow debugging is enabled.
 [5] 5 = Flow, device interface, stack interface, session manager,
and device interface expanded debugging are enabled.
 [7] 7 = This option is recommended when the device is running
under "heavy" traffic. In this mode:
The Syslog debug level automatically changes between level 5,
level 1, and level 0, depending on the device's CPU
consumption so that VoIP traffic isn’t affected.
