Version 6.6 627 Mediant 2000
User's Manual 45. Configuration Parameters Reference
Parameter Description
for E1) must belong to a channel group. Below is an example
for configuring an E1 CAS trunk (Trunk 5) with several CAS
variants:
ProtocolType_5 = 8
CASFILENAME_2='E1_R2D'
CASFILENAME_7= E_M_ImmediateTable_A-Bit.txt'
CasChannelIndex_5 = ‘1-10:2,11-20:7,21-31:2’
Notes:
 To configure this parameter, the trunk must first be stopped.
 Only one of these formats can be implemented; not both.
 When this parameter is not configured, a single CAS table for
the entire trunk is used, configured by the parameter
CASTableIndex.
[CASTablesNum]
Defines how many CAS protocol configurations files are loaded.
The valid range is 1 to 8.
Note: For this parameter to take effect, a device reset is required.
CAS State Machines Parameters
Note: For configuring the CAS State Machine table using the Web interface, see 'Configuring CAS
State Machines' on page 265.
Web: Generate Digit On Time
[CASStateMachineGenerate
DigitOnTime]
Generates digit on-time (in msec).
The value must be a positive value. The default is -1.
Web: Generate Inter Digit Time
[CASStateMachineGenerateI
nterDigitTime]
Generates digit off-time (in msec).
The value must be a positive value. The default is -1.
Web: DTMF Max Detection
Time
[CASStateMachineDTMFMax
OnDetectionTime]
Detects digit maximum on time (according to DSP detection
information event) in msec units.
The value must be a positive value. The default is -1.
Web: DTMF Min Detection
Time
[CASStateMachineDTMFMin
OnDetectionTime]
Detects digit minimum on time (according to DSP detection
information event) in msec units. The digit time length must be
longer than this value to receive a detection. Any number may be
used, but the value must be less than
CasStateMachineDTMFMaxOnDetectionTime.
The value must be a positive value. The default is -1.
Web: MAX Incoming Address
Digits
[CASStateMachineMaxNumO
fIncomingAddressDigits]
Defines the limitation for the maximum address digits that need to
be collected. After reaching this number of digits, the collection of
address digits is stopped.
The value must be an integer. The default is -1.
Web: MAX Incoming ANI Digits
[CASStateMachineMaxNumO
fIncomingANIDigits]
Defines the limitation for the maximum ANI digits that need to be
collected. After reaching this number of digits, the collection of
ANI digits is stopped.
The value must be an integer. The default is -1.
Web: Collect ANI
[CASStateMachineCollectAN
I]
In some cases, when the state machine handles the ANI
collection (not related to MFCR2), you can enable the state
machine to collect ANI or discard ANI.
 [0] No = Don't collect ANI.
 [1] Yes = Collect ANI.
