AudioCodes Mediant 2000

Version 6.6 683 Mediant 2000
User's Manual 45. Configuration Parameters Reference
Parameter Description
Web: SAS Registration
Time
EMS: Registration Time
[SASRegistrationTime]
Defines the value of the SIP Expires header that is sent in a 200 OK
response to an incoming REGISTER message when in SAS
'Emergency Mode'.
The valid range is 10 to 2,000,000. The default is 20.
Web: SAS Local SIP TCP
Port
EMS: Local SIP TCP Port
[SASLocalSIPTCPPort]
Defines the local TCP port used to send/receive SIP messages for the
SAS application. The SIP entities in the local network need to send the
registration requests to this port. When forwarding the requests to the
proxy ('Normal Mode'), this port serves as the source port.
The valid range is 1 to 65,534. The default is 5080.
Web: SAS Local SIP TLS
Port
EMS: Local SIP TLS Port
[SASLocalSIPTLSPort]
Defines the local TLS port used to send/receive SIP messages for the
SAS application. The SIP entities in the local network need to send the
registration requests to this port. When forwarding the requests to the
proxy ('Normal Mode'), this port serves as the source port.
The valid range is 1 to 65,534. The default is 5081.
Web: SAS Connection
Reuse
[SASConnectionReuse]
Enables the re-use of the same TCP connection for sessions with the
same user in the SAS application.
 [0] Disable
 [1] Enable (default)
The device can use the same TCP connection for multiple SIP
requests / responses for a specific SIP UA. The benefits of this feature
include less CPU and memory usage because fewer TCP connections
are open and reduced network congestion. For example, assume the
following:
 User A sends a REGISTER message to SAS with transport=TCP.
 User B sends an INVITE message to A using SAS.
In this scenario, the SAS application forwards the INVITE request
using the TCP connection that User A initially opened with the
REGISTER message.
Web/EMS: Enable
Record-Route
[SASEnableRecordRout
e]
Determines whether the device's SAS application adds the SIP
Record-Route header to SIP requests. This ensures that SIP
messages traverse the device's SAS agent by including the SAS IP
address in the Record-Route header.
 [0] Disable (default)
 [1] Enable
The Record-Route header is inserted in a request by a SAS proxy to
force future requests in the dialog session to be routed through the
SAS agent. Each traversed proxy in the path can insert this header,
causing all future dialogs in the session to pass through it as well.
When this feature is enabled, the SIP Record-Route header includes
the URI "lr" parameter, indicating loose routing, for example:
Record-Route: <sip:server10.biloxi.com;lr>
Web: SAS Proxy Set
EMS: Proxy Set
[SASProxySet]
Defines the Proxy Set (index number) used in SAS Normal mode to
forward REGISTER and INVITE requests from users that are served
by the SAS application.
The valid range is 0 to 5. The default is 0 (i.e., default Proxy Set).
Web: Redundant SAS
Proxy Set
EMS: Redundant Proxy
Set
Defines the Proxy Set (index number) used in SAS Emergency mode
for fallback when the user is not found in the Registered Users
database. Each time a new SIP request arrives, the SAS application
checks whether the user is listed in the registration database. If the
