Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
115
of 820
4
4.4.2.6 ProDrive Motor
Figure 68: ProDrive Motor general
4.4.2.7 Parameter overview motor
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
19.3 Motormanager status UINT 0 60 0 1:1 X
19.5 Max. drive current actual
value
FLOAT 0 10000 0 A 1:1 X
19.6 Max. drive current FLOAT 0.0 10000 1.5 A 1:1 X
19.7 Max. field current amplitude FLOAT 0 10000 0 A 1:1 X
19.8 Max. torque current FLOAT 0 10000 0 A 1:1 X
19.9 Field current preset value FLOAT -10000 10000 0 A 1:1 X
