Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
248
of 820
4.4
4.4.15.4 Description of the Parameters
131.1 Mode
By setting the appropriate bits, the following channels can be switched off independently
of one another:
131.8 Last consumer index UINT 0 0xFFFF 0 1:1
131.9 Slave settings DWORD 0 0xFFFFFFFF 0 1:1 X
131.10 Slave info UDINT 0 0xFFFFFFFF 0 1:1 X
131.11 MAC address STRING 1:1
131.12 Base Ip address UDINT 0 0xFFFFFFFF 0xC0A80000 1:1 X
131.13 DIP switch settings UDINT 0 0xFFFFFFFF 0 1:1 X
131.14 Software IP address UDINT 0 0xFFFFFFFF 0 1:1 X
131.15 Actual IP address UDINT 0 0xFFFFFFFF 0 1:1 X
131.16 Gateway UDINT 0 0xFFFFFFFF 0 1:1 X
131.17 Subnet mask UDINT 0 0xFFFFFFFF 0xffff0000 1:1 X
131.18 Fieldbus cycle time UDINT 125000 8000000 1000000 ns 1:1 X
131.19 Slave error code UDINT 0 0xFFFFFFFF 0 1:1 X
131.20 Division ratio fieldbus task UINT 1 32 1 1:1 X
131.21 Configuration profile 1 DWORD 0 0xFFFFFFFF 0x0 1:1 X
131.22 Fieldbus type WORD 0 0xFFFF 0 1:1
131.23 Options DWORD 0 0xFFFFFFFF 0 1:1 X
131.24 Profinet device name UINT 0 0xFF 0 1:1 X
131.52 Error counter fieldbus actual
values
UDINT 0 0xFFFFFFFF 0 1:1 X
131.53 Error counter fieldbus set val-
ues
UDINT 0 0xFFFFFFFF 0 1:1 X
131.55 Max error count fieldbus
actual values
UDINT 0 0xFFFFFFFF 2 1:1 X
131.56 Max error count fieldbus set
values
UDINT 0 0xFFFFFFFF 2 1:1 X
Bit Description
4 ... 0 Reserved
5: Cyclic real-time channel for EtherCAT
6: Slow service channel for managing the real-time GDP lists
7: Slow parameter channel for Microblaze GDP protocol
