Operating Modes
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
664
of 820
4.8
4.8.12.4 Description of the Parameters
166.1 Mode
The mode can only be changed if the controller is not enabled.
166.2 State
Bit no. Meaning
1 ... 0 Mode for U-f characteristic
0: Simple U-f characteristic without overcurrent protection
1: Simple U-f characteristic with overcurrent protection
2: Compensating controller for acceleration
2 Reserved
3 Current control for low speed
0: Inactive
1: Active
4 0: Increase of frequency via slip compensation
1: Compensating controller for frequency with speed controller
5 0: Ramp-up via S-curve
1: Ramp-up linear
6 0: Set value via Z166.6– (Input reference frequency)
1: Set value via ramp function generator
7 Frequency reduction:
0: Inactive
1: Active
8 Current set value
0: Current threshold motor/generator (Z166.3– / Z166.4–)
1: Current setting (Z133.22–)
15 ... 9 Reserved
Bit no. Meaning
0 Acceleration
0: negative direction of revolution
1: positive direction of revolution
1 Braking
2 Set value reached
3 Reserved
4 Positive limit of acceleration
5 Negative limit of acceleration
