Preparations
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
48
of 820
3.4
The device may only be operated in environments of the second type (industrial environ-
ment).
The destruction of the device can cause personal injury.
3.4 Preparations
Specimen installation of a BM3xxx axis unit with a Baumüller Motor DS 56-S motor
(SRS50 encoder, sine-cosine with Hiperface
®
).
The prerequisite for the commissioning is that assembly and installation have been car-
ried out correctly.
1 Make sure that the assembly is carried out correctly and, in particular, that all safety
regulations have been observed (see Assembly in the Operating Manual for the
b
maXX
®
3000 basic unit).
2 Make sure that the installation is carried out correctly and, in particular, that all safety
regulations have been observed (see Installation in the Operating Manual for the
b
maXX
®
3000 basic unit).
DANGER!
Danger to life from electric current!
If the requirements for the electrical supply are not complied with, the device may be
damaged/destroyed and consequently present a significant danger to persons.
Therefore:
m Before installation, make sure that the requirements for the electrical supply are
met.
NOTE
Pictures for the next work steps can be found in the Operating Manual for the
b
maXX
®
3000 basic unit and in the ZInstallation plan– on page 49.
