Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
311
of 820
4
4.4.22.7 Description of the Parameters
170.1 PLC control word
Controls the start-up behavior and start/stop behavior (stop, cold start, warm start, hot
start) for the SoftDrivePLC.
170.2 PLC Status
Status of the SoftDrivePlc
170.20 Write event parameter UINT UINT 0 0xFFFF 0 1:1 X
170.21 Write event parameter
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
170.22 Write event parameter REAL FLOAT 0 0xFFFFFFFF 0 1:1 X
170.30 Error code UDINT 0 0xFFFFFFFF 0 1:1 X
170.31 Error module number UINT 0 0xFFFF 0 1:1 X
170.32 Error line number UINT 0 0xFFFF 0 1:1 X
170.33 Error POU Code type UINT 0 0xFFFF 0 1:1 X
170.34 Error module name STRING 1:1 X
170.50 Run time task RT0 FLOAT 0 5000000000 0 µs 1:1 X
170.51 Run time task RT1 FLOAT 0 5000000000 0 µs 1:1 X
170.52 Run time task RT2 FLOAT 0 5000000000 0 µs 1:1 X
170.53 Run time fieldbus task FLOAT 0 5000000000 0 µs 1:1 X
170.54 Run time write event task FLOAT 0 5000000000 0 µs 1:1 X
Value Meaning
0 PLC stop
1 PLC cold start
All variables will be initialized with default values
2 PLC warm start (behavior as cold start)
3 PLC hot start
No variables are initialized.
4 ... 65535 Reserved
