Monitoring functions
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
742
of 820
5.2
5.2 Monitoring functions
Monitoring function Warning/error
Warning Error Adjustable threshold Adjustable reaction Reaction
Phase monitoring
4)
Phase failure X X - - IS
Mains failure X X X - IS
1)
Overcurrent Overcurrent motor - X - - IS
DC link DC link overvoltage - X - - IS
DC link relative undervoltage X - - - -
Overload monitoring Peak current not possible at this
time
X - - - -
Heat sink temperature Temperature > threshold 1 X - X - -
Temperature > switch-off threshold - X - - IS
Temperature of device inte-
rior
Temperature > threshold 1 X - X - -
Temperature > switch-off threshold - X - - IS
Motor temperature I
2
t threshold exceeded - X - - IS
Threshold 1 exceeded
2)
X - X - -
Threshold 2 exceeded
2)
X - X - -
Encoder short circuit and/or tem-
perature < -30°C
2)
- X - - -
Encoder not connected and/or tem-
perature > 250°C
2)
- X - - -
Maximum temperature exceeded
2)
- X X - IS
Position controller Dynamic position error - X X - SH
Static position error - X X - SH
Controller synchronization Controller not synchronous with
external signal
X X X X
3)
1)
Pulse inhibit carried out after a specifiable interval
2)
Only if KTY encoder used
3)
Adjustable
4)
Not provided for power modules
IS: pulse inhibit
SH Quick stop
X: Implemented
-: Not possible
