Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
232
of 820
4.4
4.4.13.4 Description of the Parameters
125.1 Visu Channel 1 source parameter Id
125.2 Visu Channel 2 source parameter Id
The ID number of the parameter to be visualized is entered with these parameters.
125.3 Visu command
Run command for the visualization
125.4 Visu status
Display of the internal visualization status
125.7 Visu task no
This parameter is used to specify the cycle time of the output for visualizing the data.
Value Meaning
0 Stop (deactivate visualization)
1 Run (activate visualization)
Value Meaning
0 Stop (visualization inactive)
1 Run (visualization active)
Value Meaning
0 Reserved
1 Visu cycle = 62.5 µs
2 Visu cycle = RT0-Cycle time Z1.8–; the RT0-Cycle time is set to 250 µs
by default
3 Visu cycle = 1000 µs
