Structure of the parameter overviews
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
78
of 820
4.2
*) this means the cycle of the set value generation, the cycle of the monitorings,
the cycle of the management and the cycle of the other functions of the preset
operation mode Z109.1–.
4.2 Structure of the parameter overviews
All parameter overviews are structured according to the following pattern:
Number = Number of the parameter consisting of ID of the functional block (FB) and the
numbering within the FB
Digital outputs Remaining time
Configurable status word 1 ms
Oscilloscope function Adjustable from 62,5 µs to 100 s.
Z109.1– Operation mode Task
-12 Coupled operation Fieldbus
-7 Autotuning Remaining time (manage-
ment)
-6 Spindle positioning RT1
-5 Synchronous operation with virtual master axis RT1
Synchronous operation with real master axis RT0 (set value), RT1
(Management)
-4 Position control with synchronous set of set-
points
Fieldbus
-3 Speed control with ramp function generator RT1 (default setting) or
fieldbus
-2 Current control RT0
-1 Notch position search RT1
1 Target position setting RT1
2 Speed setting 1 with ramp function generator RT1 (default setting) or
fieldbus
5 Manual drive operation RT1
6 Reference run operation RT1
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
1.1 System clock FLOAT 0 1000000000 0 sec 1:1 X
1.2 System ticks RT1 UDINT 0 0xFFFFFFFF 0 1:1 X
