Diagnosis
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
708
of 820
4.9
4.9.3.2 Description of the Parameters
104.1 Command
This parameter can be used to switch the FFT function on or off.
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
104.1 Command UDINT 0 4 0 1:1 X
104.2 Status UDINT 0 41 0 1:1 X
104.3 Signal input 1 source Pxxx UDINT 0 0xFFFFFFFF 0 1:1 X
104.4 Signal input 2 source Pxxx UDINT 0 0xFFFFFFFF 0 1:1 X
104.5 Signal input 1 / 2 axis UINT 0 0x11 0 1:1 X
104.6 Signal out target-Pxxx UDINT 0 0xFFFFFFFF 0 ID 1:1 X
104.7 FFT mode UDINT 0 0xFFFF 0 1:1 X X
104.8 FFT info DINT 0 12 0 1:1
104.9 FFT length DINT 64 4096 4096 1:1 X
104.10 FFT windowing UINT 0 5 1 1:1 X
104.11 Average number setup DINT 0 20000 16 1:1 X
104.12 Signal out amplitude FLOAT -1e+9 1e+9 0 1:1 X
104.13 Signal output offset FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.14 Frequency for sinus genera-
tor
FLOAT 0 8000 0 Hz 1:1 X
104.15 Signal out FLOAT -1e+9 1e+9 0 1:1 X
104.16 Input signal 1 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.17 Input signal 2 FLOAT -1e+9 1e+9 0.000000e+00 1:1 X
104.18 Actual average DINT 0 20000 0 1:1 X
104.19 Max. frequency FLOAT 0.000000e+00 8000 2000 Hz 1:1 X
104.20 Frequency resolution FLOAT 0.000000e+00 62.5 9.765625e-01 Hz 1:1 X
104.21 FFT data FLOAT 0 0 0 1:1 X
104.22 Prbs register length UINT 0 19 19 1:1
104.23 Prbs register clock UINT 1 0xFFFF 1 1:1
FFT Command Meaning
0 Stop
1 Run
