Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
691
of 820
4
4.9.1.2 Description of the diagnosis parameters
6.1 Standstill threshold
The standstill window describes the amount of the speed deviation of n=0. If the speed
actual value is in the standstill window, the drive will set Parameter "N=0 Message" (Pa
-
rameter Z6.2–) to 1.
6.2 Standstill status
The message is updated every 1 ms.
6.3 Actual torque direction
The torque direction of the axis is shown in this parameter.
The display is refreshed every 2 ms
6.4 Torque relating to nominal torque
Torque in percent of rated torque.
The value corresponds with the ratio of torque current to nominal torque current and is a
16 bit value (with leading signs, no decimal places).
The parameter value corresponds to the following equational format:
Value Meaning
0 The measured actual speed is NOT within the speed window set in the
Parameter "Standstill Threshold".
1 The measured actual speed is within the speed window set in the Param-
eter "Standstill Threshold".
Value Meaning
0 Torque direction positive
1 Torque direction negative
