Set Value Generators
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
418
of 820
4.6
4.6.2.2 Description of the Parameters
132.1 Mode
Control of the set value generator
132.2 Status
Status of the set value generator
132.4 Target number output UDINT 0 0xFFFFFFFF 0 1:1 X
132.10 Set value 1 FLOAT -5000000000 5000000000 0 1:1 X
132.11 Duration zone 1 UDINT 1 4294967295 1000 ms 1:1 X
132.12 Set value 2 FLOAT -5000000000 5000000000 0 1:1 X
132.13 Duration zone 2 UDINT 1 4294967295 1000 ms 1:1 X
132.14 Set value 3 FLOAT -5000000000 5000000000 0 1:1 X
132.15 Duration zone 3 UDINT 1 4294967295 1000 ms 1:1 X
132.16 Set value 4 FLOAT -5000000000 5000000000 0 1:1 X
132.17 Duration zone 4 UDINT 1 4294967295 1000 ms 1:1 X
Bit no. Meaning
0 0: Deactivate set value generation
1: Activate set value generation
1 Processing only when set value generation activated (Bit 0 = 1):
0: Switch on set value generation only when drive enabled
a)
1: Always switch on set value generation
a)
Drive state P108.6 = 4 ("Operation Enabled")
2 0: Looped operation: the set value generator starts again with the first set
value after the last phase has elapsed.
1: Single cycle: the generator runs through only one cycle of the preset set
value profile. At the end, the last set value is held.
31…3 Reserved
Bit no. Meaning
1…0 00: Set value generation is switched off
01: Set value generation is being initialized
10: Set value generation is suspended, awaiting (renewed) enabling of the
drive
11: Set value generation is switched on
3…2 Reserved
