Diagnosis
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
700
of 820
4.9
4.9.2 Oscilloscope function
The b maXX
®
controllers offers an integrated oscilloscope function for quick and easy
commissioning.
Range of oscilloscope function:
4.9.2.1 Parameter overview
Functional block: FbRsp [101]
Number of channels: 8
Sampling time: 62.5 µs to 100 s
Recording: triggered or not triggered
Triggering: m through internal status changes,
m Size change or
m external digital or analog inputs
Number of Triggers: 1
Trigger time in relation to 
memory depth:
Recording after-running period parameterizable 
(which means recording with or without prior
history related to the trigger event)
Trigger sources: m Digital signals (selection of relevant bits
through bit masks is possible) e.
g.:
n Status change
n Error or warning events
n external digital inputs
m analog signals
n Target or actual values
n Analog inputs
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
101.1 Status INT 0 5 0 1:1 X
101.2 Command INT 0 7 0 1:1 X
101.3 Channel 0 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.4 Channel 1 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.5 Channel 2 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.6 Channel 3 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.7 Channel 4 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.8 Channel 5 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
