Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
701
of 820
4
Description of the Parameters
101.1 Status
101.2 Command
101.9 Channel 6 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.10. Channel 7 source parameter
id
UDINT 0 4294967295 0 ID 1:1 X
101.11 Trigger source parameter id UDINT 0 4294967295 0 ID 1:1 X
101.12 Trigger mode UDINT 0 0x00000077 0 1:1 X
101.13 Trigger axis mask UINT 0x1 0x3 0x1 1:1 X
101.14 Trigger condition UDINT 0 0x0000003F 0 1:1 X
101.15 Trigger compare value FLOAT -5.000000e+9 5.000000e+9 0.000000e+00 1:1 X
101.16 Trigger compare mask UDINT 0 0xFFFFFFFF 0 1:1 X
101.17 Trigger cause UINT 0 1999 0 1:1 X
101.18 Sample time FLOAT 0.0000625 100 0.001 s 1:1 X
101.19 After-run time FLOAT 3.000000e-01 3.000000e+06 1.000000e+00 s 1:1 X
101.20 Recording time FLOAT 1.000000e+01 3.000000e+06 1.000000e+01 s 1:1 X
101.21 Buffer size UDINT 10000 504000 10000 DW 1:1 X
101.22 Measure time FLOAT 0 10000 0 µs 1:1 X
101.23 Scope buffer FLOAT -1.000000e+37 1.000000e+37 0.000000e+00 1:1 X
101.24 Task number UINT 1 2 2 1:1 X
Value Meaning
0 Recording stopped
1 Recording in progress
current status:
Waiting for trigger event
2 No significance
3 Trigger has occurred
Recording still in progress
Ring buffer in after-running period
4 Ring buffer can be read out
Value Meaning
0 Recording Stop
1 Recording Start
2 Activate trigger
3 Reset, deletes error, redistributes memory
