4.4.2.8 Description of the Parameters
19.3 Motor manager status
The status of the motor manager is displayed in this parameter. It shows the status of the
internal state machine.
138.15 Iq limit bipolar FLOAT 0 100 100 % 1:1 X
138.16 Speed threshold for break-
down torque limit
FLOAT 0 1e9 0 U/min 1:1 X
138.17 Factor for breakdown torque FLOAT 0 1.41 0.9 1:1 X
138.18 Iq limit breakdown torque FLOAT 0 1e9 0 A 1:1 X
138.20 Max. torque actual value UDINT 0 0xFFFFFFFF 0 Nm 1000:1 X
138.21 Torque display DINT 0x80000000 0x7FFFFFFF 0 Nm 1000:1 X
138.22 Torque limit symmetric UDINT 0 2147483647 2147483647 Nm 1000:1 X
138.24 Indication threshold torque UDINT 0 2147483647 2147483647 Nm 1000:1 X X
138.25 Status current limitation UDINT 0 0xFFFFFFFF 0 1:1 X
138.26 Limitation max current of
IPMSM
FLOAT 0 1e9 0 A 1:1 X
138.28 Hysteresis for Iq limit flag FLOAT 0 50 2 % 1:1 X
138.29 Time constant torque display FLOAT 0 1000 3 ms 1:1 X
138.30 Max. torque current actual
value
FLOAT 0 10000 0 A 1:1 X
146.1 Induction motor mode UINT 0 0xFFFF 0 1:1 X
146.13 Flux set value FLOAT -1e9 1e9 1 % 100:1 X
146.14 Actual flux FLOAT -1e9 1e9 0 % 100:1 X
146.16 Slip preset value DINT 0x80000000 0x7FFFFFFF 0 Inc
/Tab
1:1 X
Value Meaning
0 Motor manager switched off
1 Motor manager switched on
2 Pole position search completed successfully
3 Error during pole position search
9 ... 4 Reserved
10 Init. pole position search method 0
11 Pole position search method 0 active
19 ... 12 Reserved
20 Init. pole position search method 1
21 Pole position search method 1 active
