Baumuller b maXX BM3000 User Manual

Controllers
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
512
of 820
4.7
4.7.5.8 Description of the Two-level Controller Parameter with absolute Thresholds
151.1 Mode
Configuration of the absolute two-level controller
151.2 Status
State of the absolute two-level controller
151.3 Input
Parameter number of the input of the two-level controller. With value 0 no comparison to
absolute thresholds operates.
Bit Meaning
0 0: Inactive
1: Active
1 Reserved
2 0: No absolute-value generation at actual value (comparison signed)
1: Absolute-value generation at actual value (symmetrical monitoring)
4 ... 3 Performance two-level-controller output
00: Standard performance (switch on accordant hysteresis)
01: Set output only once
10: Reset output only once
11: Reserved
5 0: No automatic reset by status word bit 15
1: Automatic reset by status word bit 15
15 … 6 Reserved
Bit Meaning
0 0: Inactive
1: Active
15 … 1 Reserved
