4.4.4.5 Description of the Lh-characteristic parameters
123.39 Speed for Lh identification
Speed (in % of the nominal speed), at which the Lh identification is executed.
146.17 State Lh identification
146.19 Ramp-up time nominal speed
Ramp-up time for controlled acceleration/deceleration to nominal speed/speed = 0 due to
determine the main inductivity characteristic.
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
123.39 Speed for Lh identification FLOAT 0 0xFFFFFFFF 30 % 1:1 X
146.17 State Lh identification UINT 0 10 0 1:1 X
146.19 Rising time nominal speed FLOAT 1 1000 10 s 1:1 X
Value Description
0 Inactive
1 Initialization
2 Acceleration of nominal speed with 1.1 * magnetizing current
3 To build up
4 Wait until current and voltage are constant
5 Measuring the voltages
6 Braking to 0
7 Calculating the inductance
8 Motor control entry in table
9 Completed
10 Completed
