7 Make sure that all safety devices are connected on the supply and motor sides and
are ready for operation.
8 Make sure that the encoder for motor control (sine-cosine encoder) is connected to
the encoder evaluation module with the appropriate encoder cable.
9 Make sure that the PC/Laptop is connected to the controller.
3.4.1 Communication via the service cable
The service interface transmits controller parameters from a PC/laptop to the controller
via the parameterizing software ProDrive.
h Connect free USB-port of the PC/laptop with the controller
The driver connection was installed on the PC/laptop with ProDrive, already. The settings
of the connection (baudrate etc.) are made in ProDrive. Refer to the online-help of
ProDrive.
NOTE
The service cable BM5-K-USB-XXX must be used for the service interface X1, only.
