Preparations
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
50
of 820
3.4
Motor data 
(Identification
plate)
These data can be found, e.g., on the identification plate for the motor that you are using
for the commissioning.
The motor database is used in this example; the values in the table are provided only for
checking purposes.
Motor data 
(Data sheet)
These data can be found on the data sheet for the motor that you are using for the com-
missioning.
1)
You can also have ProDrive determine the notch angle (see ZSearching for the notch position– on page 71).
Encoder data
(Data sheet)
These data can be found on the data sheet for the encoder that you are using for the com-
missioning.
5 Make sure that the motor meets the following conditions:
m provided with a suitable encoder, in this example: SRS50 SinCos encoder
m connected to b maXX
®
3000
m ready for operation
m properly secured
m can rotate freely during commissioning
6 Make sure that switching elements for pulse enabling are connected to the b maXX
®
3000 (e.g. in a patch panel) and are functioning. Make sure that the switch is in the
rest position (inactive).
Name Value, e.g. Used for entering in the parameter list /parame-
ter
Motor type, designation DS 56-M Parameter list/Motor configuration
Z107.2– Motor type
Nominal voltage U
N
330 V Parameter list/Motor configuration
Z107.8– Motor nominal voltage
Nominal current I
N
4,0 A Parameter list/Motor configuration
Z107.9– Motor nominal current
Nominal speed n
N
3000 rpm Parameter list/Motor configuration
Z107.7– Motor nominal speed
Name Value, e.g. Used for entering in the parameter list /parame-
ter
Max. current I
mot,max
14,3 A Parameter list/Motor configuration
Z107.21– Maximum drive current
Number of pole pairs 3 Parameter list/Motor configuration
Z107.19– Pole pairs
Max. speed n
max.
6000 Parameter list/Motor configuration
Z107.26– Maximum speed mechanical
Notch angle, if specified
1)
240° Parameter list/Motor configuration
Z127.8– Encoder Offset el.
Name Value, e.g. Used for entering in the parameter list /parame-
ter
Encoder type Stegmann SRS
50/60 SinCos
encoder
With sine-cosine encoders with HIPERFACE
®
inter-
face, the encoder type is read in automatically via
the HIPERFACE
®
interface
Number of pulses 1024 Parameter list/Encoder configuration/
Z137.1– Number of pulses
