Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
369
of 820
4
4.5.2.12 Parameter overview
Functional block: FbDsv [105]
Create Data Set <n> 6 Data set to be cre-
ated
Delete Data Set <n> 7 Data set to be
deleted
Copy Data Set <x> to Data Set <y> 8 Source data set Target data set
Load Data Set <x> from Flash 9 Data set in Flash
Reserved 10
Z105.1–
Data Set Management
Command
Value Z105.8–
Source data set
Z105.9–
Target Data Set
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
105.1 Command DINT 0 10 0 1:1
105.2 Status UDINT 0 0xFFFFFFFF 0 1:1 X
105.3 Message RE-
CORD
X
105.4 Record name STRING 1:1 X X
105.5 Record id UDINT 0 0xFFFFFFFF 0 1:1 X X
105.6 Dataset index UINT 1 7 1 1:1
105.7 Valid data sets WORD 1 0x7F 1 1:1 X
105.8 Data set source UINT 0 7 0 1:1
105.9 Data set dest UINT 0 7 0 1:1
105.11 Name of complete parameter
set
STRING 1:1 X
105.12 Error count UINT 0 0xFFFF 0 1:1 X
105.13 Config Ident number UDINT 0 0xFFFFFFFF 0 1:1 X
