Page #158 background imageLoading...
Page #158 background image
Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
158
of 820
4.4
4.4.5.6 Description of the Parameters
171.1 Control word reluctance
171.3 Ld curve family
Nonlinear direct axis inductance depending on the currents Isd and Isq. The first index
shows the dependence of Id, the second of Iq.
171.11 Id Current of MTPF charac-
teristic
FLOAT -100 0 -100 A 1:1 X
171.12 Motor constant K FLOAT -1 1e9 -1 A 1:1 X
171.13 MTPF Table FLOAT -100 0 -100 % 1:1 X
171.14 Nominal flux FLOAT 0.0001 1e9 1 Vs 1:1 X
171.15 State field weakening of
IPMSM
DINT 0 10 0 1:1 X
171.16 Total reference current FLOAT -10000 10000 0 A 1:1 X
171.17 Maximal torque current from
flux
FLOAT 0 10000 0 A 1:1 X
171.20 Magnetic flux FLOAT 0.0001 1e9 0.1 Vs 1:1 X
171.21 State identification nonlinear-
ity
UINT 0 0xFFFF 0 1:1 X
Bit no. Meaning
0 Motor constant determined via Id
nom
and I
nom
1 Calculate motor constant via Lq, Ld and magnetic flux
4 … 2 Reserved
5 Start identification of Lq, Ld and magnetic flux
6 Start identification of the magnetic flux
8 ... 7 Reserved
9 Recalculation of the tables
13 ... 10 Reserved
14 Transfer of the inductances from autotuning and of the Ke factor from
motor type plate as constant values
15 Calculate MTPF table
