Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
657
of 820
4
Features
m Maximum frequency: double nominal frequency
m Minimum frequency: is limited by load inertia and actual remaining flux
m High DC link voltage (> 560 V) and a low stator resistance can lead to wrong detection
of motor operation conditions
Adjustment aid
m For a successful catch on fly of the motor, the exact knowledge of the motor parame-
ters is inevitable, especially deadtime compensation as well as rotor and stator resis-
tance. Make sure, that all steps described in chapter ZSensorless control– from page
655 have been completed during commissioning.
m If a DC link overvoltage error occurs during catch operation, parameterize Z167.3–
Catch demagnetization time
m If a overcurrent error occurs during catch operation, parameterize Z167.3– Catch de-
magnetization time
m During catch operation, the actual speed value Z18.22– settles to the actual rotor
speed. Overshoots of over 30% might occur. Take this into account to parameterize
the overspeed limits.
Required parameters
m Catch enable Z167.1–
4.8.11.3 Parameter overview
Functional block: FbMagn [160]
Functional block: FbSzl [161]
Functional block: FbFluxEstimatorOL [163]
Functional block: FbCatchOL [167]
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
160.1 Magnetization time UDINT 0 5000 200 ms 1:1 X
161.1 Minimum speed threshold
OL
UDINT 0 1800 180 Grad/s 1:1 X X
161.2 Minimum speed delay OL UDINT 0 10000 1000 ms 1:1 X X
163.1 Flux estimator gain FLOAT 50.00 1000.00 250.00 1:1 X X
167.1 Catch enable UDINT 0 1 0 1:1 X
167.2 Catch flux estimator gain FLOAT 1.0 1000.00 25.00 1:1 X
167.3 Catch demagnetization time UINT 0 4000 0 ms 1:1 X
