Baumuller b maXX BM3000 - Description of the Parameters

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
174
of 820
4.4
4.4.6.8 Description of the Parameters
14.1 Min value sin²+cos²
Minimum threshold value for (sin²+cos²) monitoring of the encoder signals in percent.
14.2 Max value sin²+cos²
Maximum threshold value for (sin²+cos²) monitoring of the encoder signals in percent.
14.3 Actual value sin²+cos²
The value is calculated from the encoder track for (sin²+cos²) monitoring.
14.4 Variance of sin²+cos²
Standardized variance of the (sin²+cos²) actual value.
137.22 Firmware version STRING 1:1 X
137.23 Firmware date STRING 1:1 X
137.24 Eprom capacity UINT 0 0xFFFF 0 Byte 1:1 X
137.25 Data storage capacity UINT 0 0xFFFF 0 Byte 1:1 X
137.26 Defined fields UINT 0 128 0 1:1 X
137.27 Datafield status UINT 0 0xFFFF 0 1:1 X
137.28 Digital resolution UINT 0 65535 0 Bit 1:1 X
137.29 Position format UINT 0 65535 0 Bit 1:1 X
137.30 Instruction set UINT 0 0xFFFF 0 1:1 X
137.31 Resolution of revolutions UINT 0 65535 0 Bit 1:1 X
137.32 Angle resolution UINT 0 65535 0 Bit 1:1 X
137.33 Signal length UDINT 0 4294967595 0 nm 1:1 X
137.34 Measure step UDINT 0 0xFFFFFFFF 0 nm 1:1 X
137.36 Alarm mask UINT 0 0xFFFF 0 1:1 X
137.37 Alarm buffer UINT 0 0xFFFF 0 1:1 X
137.38 Warning mask UINT 0 0xFFFF 0 1:1 X
137.39 Warning buffer UINT 0 0xFFFF 0 1:1 X
137.42 Parameter of OEM 1, 2 UINT 0 0xFFFF 0 1:1 X
137.43 Parameter of OEM 3, 4 UINT 0 0xFFFF 0 1:1 X
