Diagnosis
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
690
of 820
4.9
4.9 Diagnosis
4.9.1 Diagnosis
4.9.1.1 Parameter overview Diagnosis
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
6.1 Standstill threshold FLOAT 0.0 1.000000e+06 10.0 Grad/s 1:1 X
6.2 Standstill status INT 0 1 0 1:1 X
6.3 Actual torque direction UINT 0 1 0 1:1 X
6.4 Torque relating to nominal
torque
INT -1000 1000 0 % 1:1 X
6.5 Positive overspeed limit FLOAT 0.0 1.000000e+06 0 Grad/s 1:1 X
6.6 Negative overspeed limit FLOAT -1.000000e+06 0.0 0 Grad/s 1:1 X
6.7 Max. pos. speed deviation FLOAT 0.0 1.000000e+06 0 Grad/s 1:1 X
6.8 Max. neg. speed deviation FLOAT -1.000000e+06 0.0 0 Grad/s 1:1 X
6.11 Speed error response time FLOAT 0.0 100 2.0 ms 1:1 X
6.12 Speed actual value > Speed
ON threshold
FLOAT 0 1.000000e+06 18000 Grad/s 1:1 X X
6.13 Speed actual value > Speed
OFF threshold
FLOAT 0 1.000000e+06 17000 Grad/s 1:1 X X
6.14 Velocity window percentage UINT 0 65535 0 % 100:1 X X
6.20 Blockade speed limit FLOAT 0 1000000 10 Grad/s 1:1 X
6.21 Blockade time limit 1 FLOAT 0 1000000 0.5 s 1:1 X
6.22 Blockade time limit 2 FLOAT 0 1000000 5 s 1:1 X
6.25 Power unit peak current FLOAT 0.0 1000 9.0 A 1:1 X
6.26 Power unit nominal current FLOAT 0.0 1000 4,5 A 1:1 X
6.27 Power unit Ixt actual value FLOAT 0.0 1000 0.0 % 1:1 X
6.28 Motor I2t actual value FLOAT 0 1000 0.00 % 1:1 X
6.29 Motor I2t threshold FLOAT 0 1000 100 % 1:1 X
6.30 Motor apparent current
smoothed
FLOAT 0 10000 0 A 1:1 X
6.32 Motor real power smoothed FLOAT -1000000 1000000 0 kW 1:0.001 X
6.39 Motor I2t warning threshold FLOAT 0 1000 0 % 1:1 X
6.42 Smoothing time electr. motor
power display
FLOAT 0 1000 1.25 ms 1:1 X
6.43 Motor I2t monitoring mode UINT 0 0xFFFF 0 1:1 X
6.46 Motor I2t derating factors FLOAT 10 100 100 % 1:1 X
175.1 Mode PU temperature model UINT 0x0 0xFFFF 0x0 1:1 X
175.2 Status PU temperature
model
UINT 0 0xFFFF 0 1:1 X
175.15 Power unit thermal load FLOAT 0 1000 0 % 1:1 X
