122.37 Flex. master distance angle 2
The angular portion of the changed master axis travel for the segment with the number
from
Z122.35–.
122.38 Flex. slave distance revolutions 2
The revolution portion of the changed drive system travel for the segment with the number
from
Z122.35–.
122.39 Flex. slave distance angle 2
The angular portion of the changed drive system travel for the segment with the number
from
Z122.35–.
122.41 Sequence change at the end
With this parameter which is cyclical writable a coupling / decoupling point of the se-
quence change is specified. This parameter must be considered in combination with
Z122.6–.
The parameter is two-parted:
The sequence change is specified here. The change is processed by a rising edge of bit 5
of
Z108.1– "Control word".
122.42 Numerator gear factor
Numerator of the gear factor at the output of the polynomial curve generator.
122.43 Denominator gear factor
Denominator of the gear factor at the output of the polynomial curve generator.
Sequence change >122.6<
16 bit accessed segment 16 bit following segment
